Heavy Duty Submersible Speaker Microphone for Harris M/A-COM Radios

The Waveband WX-8000-M3 is a public safety-grade remote speaker microphone engineered for Harris M/A-COM radio users who operate in demanding field conditions. Built to IP67 waterproof standards includes Kevlar-reinforced cable and noise-cancelling microphone, it delivers dependable audio performance for law enforcement, fire & EMS, and military professionals.

Key Features

• IP67-rated fully submersible waterproof construction
• Noise-cancelling electret condenser microphone
• 3.5mm accessory jack for earpiece compatibility
• Volume control on speaker mic head
• Kevlar-reinforced polyurethane cable jacket
• 50 lb axial pull strength at speaker mic head
• RoHS compliant

Compatible Radios

Harris / M/A-COM / Tyco: Jaguar 700P, P5100 Series, P5200 Series, P7100 Series, P7200 Series

Technical Specifications

Cabling
Jacket: 5.5mm Polyurethane, Kevlar Reinforced

Mechanical
Axial Pull at Speaker Mic Head: 50 lbs

Speaker
Transducer: Moving coil dynamic
Impedance: 8Ω ±15% @1KHz
Sensitivity: 120 dB ±10% @1KHz
Resonance Frequency: 400Hz ±20%
Frequency Response: F0–9KHz
Rated Input Power: 0.5W | Max: 1W

Microphone
Type: Noise Cancelling
Transducer: Electret condenser
Sensitivity: -34 ±2dB @1KHz
Impedance: Max 2.2kΩ @1KHz
Directivity: Omni-directional
Frequency: 100Hz–16,000Hz
Operating Voltage: 3V standard, 10V max
Current Consumption: Max 0.5mA
S/N Ratio: Min -34dB @1KHz

Environmental
RoHS Compliant

Waveband Part #: WX-8000-M3
